Heavy Duty Bolt-Down Bollard - 4"x36"

Wall Thickness:
Schedule 40
Baseplate:
10"x10"x1/2"
Usually Ships Next DayNext Day
Color MatchColor
CustomizableCustomize
Made Here, Made BetterUSA
Diameter/Width:
4"
Height (total):
36"
Color:
High Visibility Safety Yellow
  • Heavy Duty

  • Customizable

  • Low Maintenance Finish

  • Low Install Cost

  • Steel Dome Cap

Need help selecting dimensions, wall thickness, or anchor pattern? Check out our Bolt-Down Bollards Buyer's Guide!

Quick Product Details

  • Diameter: 4” Schedule 40 carbon steel pipe

  • Height: 36” installed height

  • Baseplate: 10” x 10” x 1/2” heavy steel base

  • Mounting: 4 pre-drilled holes for 5/8” anchor bolts

  • Cap: Fully welded steel dome cap

  • Finish: Epoxy urethane coating, approx. 4 mil thickness

  • Standard Color: High Visibility Safety Yellow

  • Customization: Custom colors available at no additional cost

  • Manufacturing: Made in Texas

  • Ordering: Available to purchase online

  • Availability: Typically ships next business day.

Buy the Bollards Plus 4” x 36” Heavy Duty Bolt-Down Bollard, a durable steel safety bollard designed to protect storefronts, equipment, walkways, and building entrances from vehicle intrusion.

Product Description

This product is part of the Bollards Plus Heavy Duty Bolt-Down Bollard series, designed for high-durability protection in commercial and industrial environments. Manufactured from Schedule 40 carbon steel pipe, this bolt-down bollard provides reliable protection in low-speed traffic environments while allowing for fast installation on existing concrete slabs. Each bollard is built with a welded steel dome cap and a heavy duty 10” x 10” x 1/2” baseplate, delivering significantly greater structural strength than the thinner baseplates commonly used on imported bollards. The baseplate includes four pre-drilled 3/4” mounting holes designed for 5/8” concrete anchors, allowing contractors to securely install the bollard without excavation or deep concrete footings.

Buy Direct From the Manufacturer

Bollards Plus designs and manufactures bollards in the United States and ships directly to job sites nationwide.

Product Details

  • Model:SMB-HD
  • SKU:SMB-HD-4x36-WD-PP-SY
  • Manufacturer:Bollards Plus
  • Heavy Duty

  • Customizable

  • Low Maintenance Finish

  • Low Install Cost

  • Steel Dome Cap

Need help selecting dimensions, wall thickness, or anchor pattern? Check out our Bolt-Down Bollards Buyer's Guide!


Specifications (as shown)

Heavy Duty Bolt-Down Bollard - 4"x36" Build

  • TypeHeavy Duty
  • ShapeCylinder
  • MaterialCarbon Steel
  • Wall ThicknessSchedule 40
  • CapWelded Steel Dome
  • Diameter/Width4"
  • Outside Diameter4.50" OD
  • Height (total)36"
  • Baseplate10"x10"x1/2"
  • Holes3/4"

Finish

  • PrepBlasted
  • PrimerDTM Epoxy (2 Mil)
  • Top CoatUrethane High Gloss with Clear Coat (2 Mil)
  • ColorHigh Visibility Safety Yellow

Common Customizations

Customizations

  • BaseplateShape, Size, Thickness, Holes
  • Buy America/MTRBuy America (BABA), TAA, NAFTA
  • Cap StyleSteel Flat, Low Profile, Wet-Set, No Cap
  • ChainsWelded Chain Loop Receivers (Single or Double)
  • ColorCustom Color / Color Match
  • FillPre-filled Concrete
  • FinishPaint Type, Powder Coat, Galvanized, Bare (No Finish)
  • GussetsStiffener Plates
  • HeightAny
  • MaterialStainless Steel
  • TapeReflective Tape
